Satellite list

This site contains all satellites currently decodable by SatDump, including descriptions of each of their downlinks.

Credits for sample data/FFT images: Meti, Lego11, Aang23, Seler1500, R1chae, plugger_lockett, Henerius OH8CYV, bush22, AGcov (BI2QYN), SaveItForParts, Crosswalkersam, Digitelektro

Every signal will have a colored marker next to the name depicting its last known status:

• 🟢 Active
• 🔴 Failed/Inoperative
• 🔵 Operational but disabled
• 🟡 Unknown

Last updated: 2026-04-16 06:30:01.726780+00:00

Currently maintained by: Meti

ANGELS [NORAD 44876]

18-12-2019 • Agency: CNES

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢DB	TODO	1703 MHz	RHCP 400 ksym/s	-
TODO

Aqua [NORAD 27424]

04-05-2002 • Agency: NASA

NASA EOS satellite, operational but pending decommissining in August because of a lack of fuel the spacecraft needs to maintain its altitude. A refuelling mission was planned but cancelled due to budget cuts.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢X-band		8160 MHz	RHCP 7.5 Msym/s	-
DB + Dump
🟢S-band	TODO	2287.5 MHz	RHCP ??? ksym/s	-
Telemetry?

Arctic Weather Satellite [NORAD 60543]

16-08-2024 • Agency: ESA

Microwave imaging satellite acting as a prototype of the EPS-STERNA constellation.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢DB + Dump		1707 MHz	RHCP 1.785 Msym/s	-
Global unencrypted DB, dumps to Redu/Kiruna/Svalbard. Contains the MWR instrument (microwave imager). Dumps contain full orbit data. Signal usually suffers from significant fading when facing away from you at lower elevations. Pictured is the DB mode, dump mode has the same bandwidth but with much less filler.

Arktika-M N°1 [NORAD 47719]

28-02-2021 • Agency: Roscosmos

Same satellite bus as Elektro (Навигатор) shot into a Molniya orbit to perform high resolution Arctic region imaging.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢RDAS		7865 MHz	RHCP 30.72 Msym/s	-
Full resolution MSU-GS imagery. New image every 15 minutes, very strong carrier when idle. Transmitted near apogee (circa above 36000 km).
🔴GGAK		1703 MHz	RHCP 5 ksym/s	-
Seemingly unused GGAK downlink.
🟢DCP		1697.5 MHz	RHCP ??? sym/s	-
Contains DCP data, currently unsupported due to unknown modulation.
🔴xRIT	-	1691 MHz	RHCP -	-
Arktika satellites can broadcast xRIT just like their Elektro counterparts, but the downlink is currently unused.

Arktika-M N°2 [NORAD 58584]

16-12-2023 • Agency: Roscosmos

Same satellite bus as Elektro (Навигатор) shot into a Molniya orbit to perform high resolution Arctic region imaging.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢RDAS		7865 MHz	RHCP 30.72 Msym/s	-
Full resolution MSU-GS imagery. New image every 15 minutes, very strong carrier when idle. Transmitted near apogee (circa above 36000 km).
🟢GGAK		1703 MHz	RHCP 5 ksym/s	-
Contains GGAK and SEM data, not supported due to the lack of documentation. Spike on the left is not a part of the signal.
🟢DCP		1697.5 MHz	RHCP ??? ksym/s	-
Contains DCP data, currently unsupported due to unknown modulation.
🔴xRIT	-	1691 MHz	RHCP -	-
Arktika satellites can broadcast xRIT just like their Elektro counterparts, but the downlink is currently unused.

Aura [NORAD 28376]

05-06-2004 • Agency: NASA

NASA EOS satellite designed to perform atmosphere & ozone monitoring
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢X-band	TODO	8160 MHz	RHCP 7.5 Msym/s	-
TODO
🟢S-band	TODO	2287.5 MHz	RHCP ???	-
Telemetry?

BlueWalker-3 [NORAD 53807]

11-09-2022 • Agency: AST + SpaceMobile

Encrypted mobile communicatino satellite, contains an engineering camera.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢Dump	TODO	437.5 MHz	??? ???	-
Encrypted.
🟡S-band (WIDE)		2245 MHz	RHCP 512 ksym/s	-
Encrypted.
🟡S-band (NARROW)	TODO	2245 Msym/s	RHCP 128 ksym/s	-
Encrypted.

Brite-PL 2 [NORAD 40119]

19-08-2014 • Agency: Polish Academy of Sciences

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢Dump		2234.4 MHz	RHCP ???	-
Pictured is the signal switching from a wide to a narrow transmission

CALIPSO [NORAD 29108]

28-04-2006 • Agency: NASA + CNES

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🔴X-band		8330 MHz	RHCP ???	-
TODO
🔴S-band		2262.5 MHz	RHCP 0.839 ksym/s	-
TODO

CFOSAT [NORAD 43662]

29-10-2018 • Agency: CNAS + CNES

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢X-band	TODO	8304 MHz	RHCP 30 Msym/s	-
Dumps to Kiruna and China
🟢S-band	TODO	2262.5 MHz	RHCP ???	-
TODO

CHEOPS [NORAD 44874]

17-12-2019 • Agency: ESA

Satellite that studies extrasolar planets
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟡Dumps	-	2208.5 MHz	??? 1.142 Msym/s	-
-

Coriolis [NORAD 27640]

06-01-2003 • Agency: USSF

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢S-band DB		2221.5 MHz	RHCP 512 ksym/s	-
Only filler due to the failure of the Windsat instrument
🟡X-band dump	TODO	??? MHz	??? ???	-
Safetynet dumps to Wallops? Used to dump to Spain as well

Cryosat-2 [NORAD 36508]

08-04-2010 • Agency: ESA

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟡Dumps	TODO	8100 MHz	RHCP 60 Msym/s	-
TODO
🟡Telemetry	TODO	2221.5 MHz	RHCP ???	-
TODO

DMSP F17 [NORAD 29522]

04-11-2006 • Agency: USSF

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢RTD		2252.5 MHz	RHCP 1.024 MSym/s	-
Encrypted everywhere except the South pole, Arctic Ocean, and over mainland US. Contains two OLS channels as well as the SSMIS sounder. Pictured is the signal switching from the encrypted transmission to the unencrypted one.

DMSP F18 [NORAD 35951]

18-10-2009 • Agency: USSF

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢RTD		2252.5 MHz	RHCP 1.024 MSym/s	-
Encrypted everywhere except the South pole, Arctic Ocean, and over mainland US. Contains two OLS channels as well as the SSMIS sounder. Pictured is the signal switching from the encrypted transmission to the unencrypted one.

DSCOVR [NORAD 40390]

11-02-2015 • Agency: NOAA

Satellite stopped transmitting twice becuase of software issues, the first time being 27-06-2019 through 03-2020 and the second time being 15-07-2025 through 10-2025
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢High rate link	TODO	2215 MHz	RHCP 276 ksym/s	-
Transmits SEM data as well as EPIC instrument imagery
🟢Low rate link		2215 MHz	RHCP 40 ksym/s	-
Telemetry and some science data.

EWS-G1 (GOES-13) [NORAD 29155]

25-05-2006 - 31-10-2023 | Agency: USSF

GOES-13 management was transferred from NOAA to USSF in 02-2020 and became operational as EWS-G1 at 08-09-2020 providing imagery at 61.5°E for Indian Ocean monitoring. It was replaced by EWS-G2 following an imager failure at 31-10-2023. It is currently drifting in a graveyard orbit, still transmits CDA telemetry.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🔴GVAR		1685.7 MHz	Linear 2.11 MSym/s	-
800 m/px VIS + 4x 4 km/px IR crop of the indian ocean every 15 minutes. Full disk transmitted at 02:45Z and every 3 hours onwards.
🟢CDA telemetry		1694 MHz	Linear 40 ksym/s	-
Satellite telemetry, still transmitted.
🔴IMAGER SD	TODO	1676 MHz	Linear 2.62 Msym/s	-
Raw IMAGER instrument downlink. Functionally identical to GVAR as of right now.
🔴Sounder SD	TODO	1676 MHz	Linear 40 ksym/s	-
Transmitted on the same frequency as IMAGER SD, contains the raw SOUNDER instrument data. Given that the SOUNDER instrument is currently disabled, this downlink is empty.
🔴LRIT	TODO	1691 MHz	Linear 293 ksym/s	-
Unused downlink. Transmitter noise floor is visible.
🔴MDL	TODO	1681.5 MHz	Linear 200 ksym/s	-
Unused downlink.
🟡S-band telemetry	TODO	2209.086 MHz	??? 4 ksym/s (?)	-
Telemetry carrier.

EWS-G2 (GOES-15) [NORAD 36411]

05-05-2010 • Agency: USSF

After the failure of EWS-G1, GOES-15 management was transferred from NOAA to USSF on 22-09-2023 and the satellite was subsequently moved over to 61.5°E for Indian Ocean monitoring
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢GVAR		1685.7 MHz	Linear 2.11 MSym/s	-
800 m/px VIS + 4x 4 km/px IR crop of the indian ocean every 15 minutes. Full disk transmitted at 02:45Z and every 3 hours onwards.
🟢CDA telemetry		1694 MHz	Linear 40 ksym/s	-
Satellite telemetry. Currently not supported because the syncword is unknown.
🟢IMAGER SD	TODO	1676 MHz	Linear 2.62 Msym/s	-
Raw IMAGER instrument downlink. Functionally identical to GVAR as of right now.
🟢Sounder SD	TODO	1676 MHz	Linear 40 ksym/s	-
Transmitted on the same frequency as IMAGER SD, contains the raw SOUNDER instrument data. Given that the SOUNDER instrument is currently disabled, this downlink is empty.
🔵LRIT	TODO	1691 MHz	Linear 293 ksym/s	-
Unused downlink. Transmitter noise floor is visible.
🔴MDL	TODO	1681.5 MHz	Linear 200 ksym/s	-
Unused downlink.
🟢S-band telemetry	TODO	2209.086 MHz	??? 4 ksym/s (?)	-
Telemetry carrier.

Elektro-L N°2 [NORAD 41105]

11-12-2015 • Agency: Roscosmos

Currently positioned at the 14.5°W slot. MSU-GS has several inoperative channels, the satellite has suffered a power supply failure making it unable to transmit xRIT. It has developed a high inclination due to the lack of propellant. Undergoes periodic yaw flips which significantly alter signal strength.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🔴LRIT		1691 MHz	RHCP 294 ksym/s	Natural color
Transmitted every 00:42 UTC and every 3 hours onwards. 06:42 and 18:42 UTC are seasonal timeslots not persent during winter months. Contains 3x VIS channels, 1x Water vapour (degraded), 1x Long-wave infrared.
🔴HRIT		1691 MHz	RHCP 1.15 Msym/s	Natural Color
Transmitted every 00:12 UTC and every 3 hours onwards. 06:12 and 18:12 UTC are seasonal timeslots not persent during winter months. Contains all MSU-GS channels.
🟢GGAK		1693 MHz	RHCP 5 ksym/s	-
Contains telemetry and SEM data. Data decoding currently unsupported due to lack of documentation.
🟢DCP		1697 MHz	RHCP ??? sym/s	-
Contains DCP data, currently unsupported due to unknown modulation.
🟢RDAS		7500 MHz	LHCP 30.72 Msym/s	-
Raw MSU-GS data downlink. New image every 30 minutes due to power supply issues, very strong carrier when idle. Beamed to Moscow.
🟢Telemetry	-	3405.703 MHz	RHCP 32 ksym/s	-
Satellite telemetry

Elektro-L N°3 [NORAD 44903]

24-12-2019 • Agency: Roscosmos

Currently positioned at the 76°E slot. MSU-GS has a degraded channel 4, broken channel 10. Satellite transmissions are paused pending Elektro-L5 commissioning. Once finished, L3 is expected to replace L2.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🔵LRIT		1691 MHz	RHCP 294 ksym/s	Natural color
Disabled because of L5 commissioning.
🔵HRIT		1691 MHz	RHCP 1.15 Msym/s	Natural Color
Disabled because of L5 commissioning.
🔵GGAK		1693 MHz	RHCP 5 ksym/s	-
Contains telemetry and SEM data. Data decoding currently unsupported due to lack of documentation. Disabled because of L5 commissioning.
🔵DCP		1697 MHz	RHCP ???	-
Disabled because of L5 commissioning.
🔵RDAS		7500 MHz	RHCP 30.72 Msym/s	-
Disabled because of L5 commissining.
🟢Telemetry	-	3405.703 MHz	RHCP 32 ksym/s	-
Satellite telemetry

Elektro-L N°4 [NORAD 55506]

02-05-2023 • Agency: Roscosmos

Currently positioned at the 165.75°E slot.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢LRIT		1691 MHz	RHCP 294 ksym/s	Natural color
Transmitted every 00:42 UTC and every 3 hours onwards. 06:42 and 18:42 UTC are seasonal timeslots not persent during winter months. Channels are broadcasted seemingly at random, broadcasts are often skipped. Transmission abruptly shuts down after 15 minutes.
🟢HRIT		1691 MHz	RHCP 1.15 Msym/s	Natural Color
Transmitted every 00:12 UTC and every 3 hours onwards. 06:12 and 18:12 UTC are seasonal timeslots not persent during winter months. Contains all MSU-GS channels.
🟢GGAK		1693 MHz	RHCP 5 ksym/s	-
Contains telemetry and SEM data. Data decoding currently unsupported due to lack of documentation.
🟢DCP		1697 MHz	RHCP ???	-
Contains DCP data, currently unsupported due to unknown modulation.
🟢RDAS		7500 MHz	LHCP 30.72 Msym/s	-
Raw MSU-GS data downlink. New image every 15 minutes, very strong carrier when idle. Beamed to Vladivostok.
🟢Telemetry	-	3405.703 MHz	RHCP 32 ksym/s	-
Satellite telemetry

Elektro-L N°5 [NORAD 67756]

02-12-2026 • Agency: Roscosmos

Newest Elektro satellite from Roscosmos, currently commissioning at 76°E. Transmissions from the satellite are still sporadic.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢LRIT		1691 MHz	RHCP 294 ksym/s	Natural color
Transmitted sporadically around 08:00Z, potential timeslots are X:12Z and every 15 minutes onwards.
🟢HRIT		1691 MHz	RHCP 1.15 Msym/s	Natural Color
Transmitted sporadically around 08:00Z, potential timeslots are X:12Z and every 15 minutes onwards.
🟢GGAK		1693 MHz	RHCP 5 ksym/s	-
Contains telemetry and SEM data. Data decoding currently unsupported due to lack of documentation.
🟢DCP		1697 MHz	RHCP ???	-
Contains DCP data, currently unsupported due to unknown modulation.
🟢RDAS		7500 MHz	LHCP 30.72 Msym/s	-
Raw MSU-GS data downlink. New image every 15 minutes, very strong carrier when idle. Beamed to Vladivostok.
🟢Telemetry	-	3405.703 MHz	RHCP 32 ksym/s	-
Satellite telemetry

FengYun 2G [NORAD 43491]

05-06-2018 • Agency: NSMC

Spin-stabilized geostationary satellite. Has a high inclination due to low propellant, is positioned at 99.5°E
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢S-VISSR		1687.5 MHz	Linear 660 ksym/s	False color FD
1.25 km/px VIS channel and 4x 5 km/px channels, transmitted every hour at XX:00. Second timeslot is at XX:30, is transmitted 01:30Z and every 4 hours after.
🔴LRIT	TODO	1690.5 MHz	Linear ??? ksym/s	-
Unused downlink.
🟢CDAS raw data		1681.6 MHz	Linear 7 Msym/s	-
Raw S-VISSR sensor downlink, transmitted right next to the 1687.5 MHz downlink. Line is transmitted in real time, groundstation processes it and *stretches* it (The S in S-VISSR), then uplinks it to the satellite so it can be downlinked at a lower symbol rate over the 1687.5 MHz transmission. See how the transmission lines up with the gaps of S-VISSR on the FFT picture. Not supported due to the lack of sample data.
🟢Telemetry		1702.5 MHz	Linear N/A (analogue)	-
Always active telemetry downlink.

FengYun 2H [NORAD 43491]

05-06-2018 • Agency: NSMC

Last spin-stabilized geostationary FengYun-2 satellite. Positioned at 79°E
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢S-VISSR		1687.5 MHz	Linear 660 ksym/s	False color FD
1.25 km/px VIS channel and 4x 5 km/px channels, transmitted every hour at XX:00. Second timeslot at XX:30 transmits every hour, but only finishes the full disk at 05:30Z and every 6 hours onwards. Otherwise, LRIT is transmitted instead and the full disk gets cut off at XX:48Z.
🟢LRIT	TODO	1690.5 MHz	Linear ??? ksym/s	-
Transmitted every 3 hours starting at 00:48 except 05:48Z. Does not transmit any imagery, is only the transmitter's test pattern.
🟢CDAS raw data		1681.6 MHz	Linear 7 Msym/s	-
Raw S-VISSR sensor downlink, transmitted right next to the 1687.5 MHz downlink. Line is transmitted in real time, groundstation processes it and *stretches* it (The S in S-VISSR), then uplinks it to the satellite so it can be downlinked at a lower symbol rate over the 1687.5 MHz transmission. See how the transmission lines up with the gaps of S-VISSR on the FFT picture. Not supported due to the lack of sample data.
🟢Telemetry		1702.5 MHz	Linear N/A (analogue)	-
Always active telemetry downlink.

FengYun 3A [NORAD 32958]

27-05-2008 - 05-01-2015 | Agency: NSMC

Prototype FengYun 3 satellite, transmitted true color on L-band
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🔴AHRPT		1704.5 MHz	RHCP 2.8 Msym/s	-
Full resolution DB imagery from all instruments
🔴MPT	-	7775 MHz	RHCP 18.7 Msym/s	-
-
🔴DPT	-	8145.95 Msym/s	RHCP 62 Msym/s
Delayed Picture Transmisison - full orbit instrument dump
🔴Telemetry	TODO	22XX MHz	LHCP 4096 sym/s	-
Telemetry downlink

FengYun 3B [NORAD 37214]

04-11-2010 - 2021 | Agency: NSMC

Prototype FengYun 3 satellite, transmitted true color on L-band
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🔴AHRPT		1704.5 MHz	RHCP 2.8 Msym/s	-
Full resolution DB imagery from all instruments
🔴MPT	-	7775 MHz	RHCP 18.7 Msym/s	-
-
🔴DPT	-	8145.95 Msym/s	RHCP 62 Msym/s
Delayed Picture Transmisison - full orbit instrument dump
🔴Telemetry	TODO	22XX MHz	LHCP 4096 sym/s	-
Telemetry downlink

FengYun 3C [NORAD 39260]

23-09-2013 - 11-2024 | Agency: NSMC

Last operational Fengyun 3 satellite that transmitted true color L-band.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🔴AHRPT		1704.5 MHz	RHCP 2.6 Msym/s	-
Full resolution DB imagery from all instruments
🔴MPT	-	??? MHz	LHCP 18.7 Msym/s	-
-
🔴DPT	-	8145.95 Msym/s	RHCP 62 Msym/s
Delayed Picture Transmisison - full orbit instrument dump
🔴Telemetry	TODO	22XX MHz	LHCP 4096 sym/s	-
Telemetry downlink

FengYun 3D [NORAD 43010]

14-11-2017 • Agency: NSMC

Low-earth-orbiting operational satellite with an ECT of 14:00 local time (asecending).
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢AHRPT		7820 MHz	RHCP 30 Msym/s	-
Full resolution DB from all instruments
🟢DPT (Dump)	TODO	8250 MHz	RHCP 150 Msym/s	-
Delayed Picture Transmission - Full orbit data dump. Omnidirectional dumps to Kiruna, Chinese groundstations
🟢Telemetry		22XX MHz	LHCP 4096 sym/s	-
Telemetry downlink

FengYun 3E [NORAD 49008]

04-07-2021 • Agency: NSMC

Low-earth-orbiting operational satellite with an ECT of 05:40 local time (descending). This satellite’s payload is designed for terminator imaging in addition to sun imaging with its XEUVI instrument. The unique orbit allows for very low angles of illumination, allowing measurement of not usually observable atmospheric characteristics.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢AHRPT		7860 MHz	RHCP 38.4 Msym/s	-
Full resolution DB from all instruments
🟢DPT (Dump)	TODO	8212.5 MHz	RHCP 225 Msym/s	-
Delayed Picture Transmission - Full orbit data dump. Omnidirectional dumps to Kiruna, Chinese groundstations
🟢Telemetry		2252.9 MHz	LHCP 8192 sym/s	-
Telemetry downlink

FengYun 3F [NORAD 57490]

03-08-2023 • Agency: NSMC

Low-earth-orbiting operational satellite with an ECT of 10:00 local time (descending). The MWRI-2 instrument is damaged, with the dish presumed to be stuck. This has rendered the instrument inoperative.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢AHRPT	TODO	7790 MHz	LHCP 38.4 Msym/s	-
Full resolution DB from all instruments
🟢DPT (Dump)	TODO	8212.5 MHz	RHCP 225 Msym/s	-
Delayed Picture Transmission - Full orbit data dump. Omnidirectional dumps to Kiruna, Chinese groundstations
🟢Telemetry	TODO	???	LHCP 8192 sym/s	-
Telemetry downlink

FengYun 3G [NORAD 56232]

16-04-2023 • Agency: NSMC

Currently the only satellite from the Fengyun 3 series to be flown in a drifting orbit rather than a polar one. The low altitude means that the satellite has to be periodically reboosted due to atmospheric drag. When this happens the broadcasts are disabled. The instrumentation is designed for rainfall measurement. The MWRI-RM is disabled for unknown reasons, with a possibility of it having failed.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢AHRPT		7790 MHz	RHCP 6 Msym/s	-
Full resolution DB from all instruments. Quite strong due to low symbol rate and low orbital height.
🟡DPT (Dump)	TODO	??? MHz	??? 225 Msym/s	-
Delayed Picture Transmission - Full orbit data dump. Omnidirectional dumps to Chinese groundstations

FengYun 3H [NORAD 65815]

26-09-2025 • Agency: NSMC

Low-earth-orbiting operational satellite with an ECT of 14:00 local time (ascending)
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢AHRPT		7860 MHz	LHCP 38.4 Msym/s	-
Full resolution DB from all instruments
🟡DPT (Dump)	TODO	8212.5 MHz	??? 225 Msym/s	-
Delayed Picture Transmission - Full orbit data dump. Omnidirectional dumps to Kiruna, Chinese groundstations
🟢Telemetry	TODO	22XX MHz	LHCP 8192 sym/s	-
Telemetry downlink

FengYun 4A [NORAD 41882]

10-12-2016 • Agency: NSMC

Geostationary satellite, primarily used for testing the Fengyun 4 bus. Currently positioned at 123.5°E
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟡LRIT	TODO	1697 MHz	Linear 90 ksym/s	-
Encrypted, clear imagery every hour (?). Low bit depth, imagery looks crunchy
🟡HRIT	TODO	1681 MHz	Linear 1 Msym/s	-
TODO

FengYun 4B [NORAD 48808]

02-06-2021 • Agency: NSMC

Geostationary satellite, currently operational at 105°E
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟡LRIT	TODO	1697 MHz	Linear 120 ksym/s	-
Encrypted, clear imagery every hour (?). Low bit depth, imagery looks crunchy
🟡HRIT	TODO	1681 MHz	Linear 1 Msym/s	-
TODO

FengYun 4C [NORAD 67246]

26-12-2026 • Agency: NSMC

Geostationary satellite, currently undergoing commissioning at 133°E
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟡LRIT	TODO	1697 MHz	Linear 120 ksym/s	-
Encrypted, clear imagery every hour (?). Low bit depth, imagery looks crunchy
🟡HRIT	TODO	1681 MHz	Linear 1 Msym/s	-
TODO

Formosat-5 [NORAD 42920]

24-08-2017 • Agency: NSO

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟡S-band dump	TODO	2215 MHz	??? 1.6 Msym/s	-
Dumps to Kiruna.
🟡X-band dump	TODO	??? MHz	??? ???	-
Dumps to Kiruna. Likely encrypted.

GCOM-C1 [NORAD 43065]

23-12-2017 • Agency: JAXA

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟡S-band dump	TODO	2220 MHz	RHCP ???	-
Dumps to Kiruna.
🟡X-band dump	TODO	8105 MHz	RHCP 69.416 Msym/s	-
Dumps to Svalbard.

GCOM-W1 [NORAD 38337]

17-05-2012 • Agency: JAXA

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟡S-band dump	TODO	2220 MHz	RHCP ???	-
Dumps to Kiruna.
🟡X-band dump	TODO	8245 MHz	RHCP 10 Msym/s	-
Dumps to Svalbard.

GEO-KOMPSAT 2A [NORAD 43823]

04-12-2018 • Agency: KARI

Geostationary satellite currently positioned at 128.2°E. Unlike its sister satellite, 2B, it does full-disk Earth imaging.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢LRIT		1692.14 MHz	Linear 128 ksym/s	Clean longwave IR
Very strong, 1x 4 km/px IR as well as miscallenous data every 10 minutes
🟢HRIT		1695.4 MHz	Linear 3 Msym/s	Raw channel 1
1x 1 km/px VIS, 4x 4 km/px IR every 10 minutes. You can see it switching from filler to data on the FFT.
🟢UHRIT		8070 MHz	LHCP 15.63 Msym/s	-
Contains all AMI channels at a full resolution - as high as 0.5 km/px with VI006
🟢Raw data		8300 MHz	RHCP 65 Msym/s	-
Omnidirectional raw sensor downlink.
🟢CDAS		1687 MHz	RHCP 3.096 msym/s	-
It is suspected this downlink is from COMS-1, but we have no way to confirm as it has never transimtted any data. It used to be the raw downlink from the COMS-1 satellite, GK2A is known to feature compatibility with the COMS downlinks namely in its xRIT platforms.

GOES-14 [NORAD 35491]

27-06-2009 • Agency: NOAA

Currently in storage mode.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🔵GVAR		1685.7 MHz	Linear 2.11 MSym/s	-
800 m/px VIS + 4x 4 km/px IR crop of the indian ocean every 15 minutes. Full disk transmitted at 02:45Z and every 3 hours onwards.
🟢CDA telemetry		1694 MHz	Linear 40 ksym/s	-
Satellite telemetry, still transmitted.
🔵IMAGER SD	TODO	1676 MHz	Linear 2.62 Msym/s	-
Raw IMAGER instrument downlink. Functionally identical to GVAR as of right now.
🔵Sounder SD	TODO	1676 MHz	Linear 40 ksym/s	-
Transmitted on the same frequency as IMAGER SD, contains the raw SOUNDER instrument data. Given that the SOUNDER instrument is currently disabled, this downlink is empty.
🔵LRIT	TODO	1691 MHz	Linear 293 ksym/s	-
Unused downlink.
🔵MDL	TODO	1681.5 MHz	Linear 200 ksym/s	-
Unused downlink.
🟡S-band telemetry	TODO	2209.086 MHz	??? 4 ksym/s (?)	-
Telemetry carrier.

GOES-16 [NORAD 41866]

19-11-2016 • Agency: NOAA

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🔵HRIT		1694.1 MHz	linear 927 ksym/s	-
GOES 16 FD: 1x VIS + 6x IR at 2 km/px every 30 minutes, 1x VIS + 2x IR mesoscale every 15 minutes, other operational GOES 1x IR at 4 km/px every hour, Himawari 1x VIS + 2x IR at 4 km/px every hour, Meteosat: 1x IR at 15 km/px every hour, Miscallenous EMWIN
🔵GRB		1686.6 MHz	RHCP+LHCP 8.67 Msym/s	(RHCP) Full-disk RGB 135 (RHCP) CONUS RGB 135 (RHCP) Mesoscale RGB 135 (RHCP) 171 angstrom SUVI (RHCP) 304 angstrom SUVI
Half the data is transmitted over RHCP, half over LHCP. LHCP contains ABI channels 2,7,8,10,14,15,16 while RHCP contains ABI chanels 1,3,4,5,6,9,11,12,13, GOES lightning mapper, SUVI imagery, SEM data. All channels transmitted in the LHCP broadcast (besides 10 and 16) are transmitted in HRIT as well, making RHCP much more interesting to receive
🟢CDA telemetry		1693 MHz	Linear 40 ksym/s	-
Telemetry broadcast, can be used to verify setup functionality
🔵DCP		1680 MHz	RHCP N/A	-
DCP data from terrestrial uplink stations.
🔵Raw downlink	TODO	8220 MHz	??? 60 Msym/s	-
Beamed to Wallops

GOES-17 [NORAD 43226]

01-03-2018 • Agency: NOAA

Geostationary satellite of the GOES-R series, currently positioned at 104.7°W acting as a backup. The satellite’s ABI instrument had cooling issues, degrading the quality of infrared channels.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🔵HRIT		1694.1 MHz	linear 927 ksym/s	-
GOES 17 FD: 1x VIS + 6x IR at 2 km/px every 30 minutes, 1x VIS + 2x IR mesoscale every 15 minutes, other operational GOES 1x IR at 4 km/px every hour, Himawari 1x VIS + 2x IR at 4 km/px every hour, Meteosat: 1x IR at 15 km/px every hour, Miscallenous EMWIN
🔵GRB		1686.6 MHz	RHCP+LHCP 8.67 Msym/s	(RHCP) Full-disk RGB 135 (RHCP) CONUS RGB 135 (RHCP) Mesoscale RGB 135 (RHCP) 171 angstrom SUVI (RHCP) 304 angstrom SUVI
Half the data is transmitted over RHCP, half over LHCP. LHCP contains ABI channels 2,7,8,10,14,15,16 while RHCP contains ABI chanels 1,3,4,5,6,9,11,12,13, GOES lightning mapper, SUVI imagery, SEM data. All channels transmitted in the LHCP broadcast (besides 10 and 16) are transmitted in HRIT as well, making RHCP much more interesting to receive
🟢CDA telemetry		1693 MHz	Linear 40 ksym/s	-
Telemetry broadcast, can be used to verify setup functionality
🔵DCP		1680 MHz	RHCP N/A	-
DCP data from terrestrial uplink stations.
🔵Raw downlink	TODO	8220 MHz	??? 60 Msym/s	-
Beamed to Wallops

GOES-18 [NORAD 51850]

01-03-2022 • Agency: NOAA

Geostationary satellite of the GOES-R series, currently positioned at 137°W operating as Goes-West.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢HRIT		1694.1 MHz	linear 927 ksym/s	-
GOES 18 FD: 1x VIS + 6x IR at 2 km/px every 30 minutes, 1x VIS + 2x IR mesoscale every 15 minutes, other operational GOES 1x IR at 4 km/px every hour, Himawari 1x VIS + 2x IR at 4 km/px every hour, Meteosat: 1x IR at 15 km/px every hour, Miscallenous EMWIN
🟢GRB		1686.6 MHz	RHCP+LHCP 8.67 Msym/s	(RHCP) Full-disk RGB 135 (RHCP) CONUS RGB 135 (RHCP) Mesoscale RGB 135 (RHCP) 171 angstrom SUVI (RHCP) 304 angstrom SUVI
Half the data is transmitted over RHCP, half over LHCP. LHCP contains ABI channels 2,7,8,10,14,15,16 while RHCP contains ABI chanels 1,3,4,5,6,9,11,12,13, GOES lightning mapper, SUVI imagery, SEM data. All channels transmitted in the LHCP broadcast (besides 10 and 16) are transmitted in HRIT as well, making RHCP much more interesting to receive
🟢CDA telemetry		1693 MHz	Linear 40 ksym/s	-
Telemetry broadcast, can be used to verify setup functionality
🟢DCP		1680 MHz	RHCP N/A	-
DCP data from terrestrial uplink stations.
🟢Raw downlink	TODO	8220 MHz	??? 60 Msym/s	-
Beamed to Wallops

GOES-19 [NORAD 60133]

25-06-2024 • Agency: NOAA

Last geostationary satellite of the GOES-R series, currently positioned at 75.2°W operating as Goes-East.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢HRIT		1694.1 MHz	linear 927 ksym/s	-
GOES 19 FD: 1x VIS + 6x IR at 2 km/px every 30 minutes, 1x VIS + 2x IR mesoscale every 15 minutes, other operational GOES 1x IR at 4 km/px every hour, Himawari 1x VIS + 2x IR at 4 km/px every hour, Meteosat: 1x IR at 15 km/px every hour, Miscallenous EMWIN
🟢GRB		1686.6 MHz	RHCP+LHCP 8.67 Msym/s	(RHCP) Full-disk RGB 135 (RHCP) CONUS RGB 135 (RHCP) Mesoscale RGB 135 (RHCP) 171 angstrom SUVI (RHCP) 304 angstrom SUVI
Half the data is transmitted over RHCP, half over LHCP. LHCP contains ABI channels 2,7,8,10,14,15,16 while RHCP contains ABI chanels 1,3,4,5,6,9,11,12,13, GOES lightning mapper, SUVI imagery, SEM data. All channels transmitted in the LHCP broadcast (besides 10 and 16) are transmitted in HRIT as well, making RHCP much more interesting to receive
🟢CDA telemetry		1693 MHz	Linear 40 ksym/s	-
Telemetry broadcast, can be used to verify setup functionality
🟢DCP		1680 MHz	RHCP N/A	-
DCP data from terrestrial uplink stations.
🟢Raw downlink	TODO	8220 MHz	??? 60 Msym/s	-
Beamed to Wallops

GRACE-FO 1 [NORAD 43476]

22-05-2018 • Agency: NASA + DLR

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟡Dump	TODO	2211 MHz	RHCP 1.5 Msym/s	-
Dumps to Svalbard

GRACE-FO 2 [NORAD 43477]

22-05-2018 • Agency: NASA + DLR

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟡Dump	TODO	2211 MHz	RHCP 1.5 Msym/s	-
Dumps to Svalbard. Possibly inactive

Gazelle (OTB-3, Argos-4) [NORAD 54023]

07-10-2022 • Agency: GA-EMS

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢ARGOS		1703 MHz	RHCP 1 Msym/s	-
Commonly spotted in L-band, as it is active globally.

Hinode [NORAD 29479]

22-11-2006 • Agency: JAXA

After its X-band transmitter failed, this satellite broadcasts all of its instruments over the S-band downlink to several groundstations as often as possible
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢S-band dumps		2256.22 MHz	RHCP 262 ksym/s	-
Active whenever in range of its groundstations, contains operational data. Multiple receptions might have to be chained together to receive a full dataset.
🟢Telemetry	TODO	2256.22 MHz	RHCP 65.6 ksym/s	-
Active whenever the satellite isn't dumping data
🔴X-band dumps		8460.81 MHz	- -	-
Failed transmitter

INTEGRAL [NORAD 27540]

17-10-2002 - 28-02-2025 | Agency: ESA

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟡Dump	TODO	2215 MHz	??? ???	-
TODO

IRIS [NORAD 39197]

28-06-2013 • Agency: NASA

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟡S-band dump		2220.8 MHz	RHCP 512 ksym/s	-
TODO
🟡X-band dump	TODO	8483 MHz	RHCP 7.5 Msym/s	-
TODO

Jason-3 [NORAD 41240]

17-01-2016 • Agency: EUMETSAT + NASA

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢Dump		2215.92 MHz	LHCP 838 ksym/s	-
TODO

Landsat 8 [NORAD 39084]

11-02-2013 • Agency: NASA + USGS

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢X-band data	TODO	8200.5 MHz	LHCP 220.4 Msym/s	-
Direct broadcast when in range of ground stations (no specific list is available, but most of the world is covered). Disabled over the sea.
🟢S-band dump	TODO	2282.3 MHz	LHCP 1.067 Msym/s	-
Dumps to Kiruna and Svalbard

Landsat 9 [NORAD 49260]

27-09-2021 • Agency: NASA + USGS

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢X-band data	TODO	8200.5 MHz	LHCP 220.4 Msym/s	-
Direct broadcast when in range of ground stations (no specific list is available, but most of the world is covered). Disabled over the sea.
🟢S-band dump	TODO	2282.3 MHz	LHCP 1.067 Msym/s	-
Dumps to Kiruna and Svalbard

MATS [NORAD 54227]

04-11-2022 • Agency: OHB Sweden

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢Dumps	TODO	2214 MHz	RHCP 1.562 MHz	-
Dumps to Kiruna

MetOp-B [NORAD 38771]

17-09-2012 • Agency: EUMETSAT

Low-earth-orbiting operational satellite with an ECT of 09:00 local time (descending). QPSK modulator has experienced a few issues leading to receptions having degraded SNR.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢AHRPT		1701.3 MHz	RHCP 2.33 Msym/s	-
Full resolution DB imagery from all instruments. Suffers from intermittent modulator issues causing a distorted constellation and lower SNR than MetOp-C.
🟢X-band dump		7800 Mhz	RHCP 35 Msym/s	-
In essence just faster AHRPT, transmits full-orbit imagery from all instruments. Omnidirectional dumps to Svalbard.
🟢Telemetry		2230 MHz	RHCP ???	-
Telemetry broadcast.
🔵LRPT	-	137.1/.9125 MHz	RHCP 72 ksym/s	-
Inactive due to interference with HIRS. Even though the HIRS instrument has failed, the broadcast remains off.

MetOp-C [NORAD 43689]

07-11-2018 • Agency: EUMETSAT

Low-earth-orbiting operational satellite with an ECT of 09:31 local time (descending). MHS instrument has striping present on a few channels.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢AHRPT		1701.3 MHz	RHCP 2.33 Msym/s	-
Full resolution DB imagery from all instruments.
🟢X-band dump		7800 Mhz	RHCP 35 Msym/s	-
In essence just faster AHRPT, transmits full-orbit imagery from all instruments. Omnidirectional dumps to Svalbard.
🟢Telemetry		2230 MHz	RHCP ???	-
Telemetry broadcast.
🔵LRPT	-	137.1/.9125 MHz	RHCP 72 ksym/s	-
Inactive due to interference with HIRS. Even though the HIRS instrument has failed, the broadcast remains off.

MetOp-SG A1 [NORAD 65159]

13-08-2025 • Agency: ESA

Latest satellite launched by ESA, built to replace the Metop-FG (first-generation) series.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢DDB	TODO	7825 MHz	RHCP 93.3 Msym/s	-
Direct broadcast from all instruments
🟢Ka-band 1	TODO	26295 MHz	TODO TODO	-
TODO: Verify
🟢Ka-band 2	TODO	26700 MHz	TODO TODO	-
TODO: Verify
🟢Telemetry	TODO	2231.6 MHz	TODO TODO	-
TODO

Meteor-M N°2-2 [NORAD 44387]

05-07-2019 • Agency: Roscosmos

LRPT was only active for a few months after launch due to a micrometeorite strike in 12-2019. This caused a leak of thermal transfer gas rendering LRPT inoperable. Satellite was moved to storage mode on 07-2024 due to orbital proximity to Meteor-M N°2-4.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🔴LRPT		137.1/.9 MHz	RHCP 2x 665.4 ksym/s	-
3 JPEG-compressed 1 km/px channels. 3x VIS during summer, 2x VIS + 1x IR during winter. Rendered inoperable due to micrometeorite strike.
🔵HRPT		1700 MHz	RHCP 2x 665.4 ksym/s	Natural color 221 Day microphysics
Full resolution 6x MSU-MR channels at 1 km/px, MTVZA
🟢Telemetry	-	3405.235 MHz	RHCP 32 ksym/s	-
Telemetry broadcast, might be seen locking onto a groundstation (drifting). Currently not supported.
🔵MTVZA dump		8128 MHz	RHCP 15.36 Msym/s	-
MTVZA data from several orbits. Omnidirectional dumps to Moscow, Novosibirsk, Khabrovsk. Narrow BPSK.
🔵IKFS dump	-	??? MHz	RHCP 15.36 Msym/s	-
Dumps from the IKFS instrument, not received yet - unconfirmed. Omnidirectional dumps to Khabrovsk. Narrow QPSK.
🔵KMSS DB	-	8128/8320 MHz	RHCP 61.44 Msym/s	-
Direct broadcast from the KMSS instrument, active over Russia, Europe, possibly the Carribean and Brazil as well (unconfirmed). Wide BPSK.
🔵Main Dump	-	8320 MHz	RHCP 61.44 Msym/s	-
KMSS/MSU-MR/Severjanin-M + MeteoSAR instrument data, only KMSS supported as of right now. Omnidirectional dumps to Moscow, Novosibirsk, Khabrovsk. Wide QPSK.

Meteor-M N°2-3 [NORAD 57166]

27-06-2023 • Agency: Roscosmos

VHF antenna didn’t deploy properly due to extended storage. Wide X-band transmitter isn’t used. LRPT JPEG compressor has minor issues from time to time causing pixelated imagery, the satellite has a watchdog that restarts it after a few orbits.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢LRPT		137.1/.9 MHz	RHCP 2x 665.4 ksym/s	221
3 JPEG-compressed 1 km/px channels. 3x VIS during summer, 2x VIS + 1x IR during winter
🟢HRPT		1700 MHz	RHCP 2x 665.4 ksym/s	Natural color 221 Day microphysics
Full resolution 6x MSU-MR channels at 1 km/px, MTVZA
🟢Telemetry	-	3405.235 MHz	RHCP 32 ksym/s	-
Telemetry broadcast, might be seen locking onto a groundstation (drifting). Currently not supported.
🟢MTVZA dump		8128 MHz	RHCP 15.36 Msym/s	-
MTVZA data from several orbits. Omnidirectional dumps to Moscow, Novosibirsk, Khabrovsk. Narrow BPSK.
🟡IKFS dump	-	??? MHz	RHCP 15.36 Msym/s	-
Dumps from the IKFS instrument, not received yet - unconfirmed. Omnidirectional dumps to Khabrovsk. Narrow QPSK.
🔴KMSS DB	TODO	8128/8320 MHz	RHCP 61.44 Msym/s	-
Direct broadcast from the KMSS instrument, active over Russia, Europe, possibly the Carribean and Brazil as well (unconfirmed). Wide BPSK.
🔴Main Dump	TODO	8320 MHz	RHCP 61.44 Msym/s	-
KMSS/MSU-MR/Severjanin-M + MeteoSAR instrument data, only KMSS supported as of right now. Omnidirectional dumps to Moscow, Novosibirsk, Khabrovsk. Wide QPSK.

Meteor-M N°2-4 [NORAD 59051]

29-02-2024 • Agency: Roscosmos

First fully operational Meteor-M satellite. LRPT JPEG compressor has minor issues from time to time causing pixelated imagery, the satellite has a watchdog that restarts it after a few orbits.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢LRPT		137.1/.9 MHz	RHCP 72/80 ksym/s	221
3 JPEG-compressed 1 km/px channels. 3x VIS during summer, 2x VIS + 1x IR during winter. 72k mode used normally, 80k only just after launch for testing.
🟢HRPT		1700 MHz	RHCP 2x 665.4 ksym/s	Natural color 221 Day microphysics
Full resolution 6x MSU-MR channels at 1 km/px, MTVZA
🟢Telemetry	-	3405.235 MHz	RHCP 32 ksym/s	-
Telemetry broadcast, might be seen locking onto a groundstation (drifting). Currently not supported.
🟢MTVZA dump		8128 MHz	RHCP 15.36 Msym/s	-
MTVZA data from several orbits. Omnidirectional dumps to Moscow, Novosibirsk, Khabrovsk. Narrow BPSK.
🟡IKFS dump	-	??? MHz	RHCP 15.36 Msym/s	-
Dumps from the IKFS instrument, not received yet - unconfirmed. Omnidirectional dumps to Khabrovsk. Narrow QPSK.
🟢KMSS DB	-	8128/8320 MHz	RHCP 61.44 Msym/s	-
Direct broadcast from the KMSS instrument, active over Russia, Europe, possibly the Carribean and Brazil as well (unconfirmed). Wide BPSK.
🟢Main Dump	-	8320 MHz	RHCP 61.44 Msym/s	-
KMSS/MSU-MR/Severjanin-M + MeteoSAR instrument data, only KMSS supported as of right now. Omnidirectional dumps to Moscow, Novosibirsk, Khabrovsk. Wide QPSK.

Meteosat-10 (MSG-3) [NORAD 38552]

05-06-2012 • Agency: EUMETSAT

Currently positioned at 0°.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢PGS Raw data		1686.83 MHz	Linear 3.75 msym/s	-
Contains all raw SEVIRI channels - 1x panchromatic at 1.6 km/px, 3x VIS and 9x IR all at 4.8 km/px. New image every 15 minutes in standard FD scanning mode, every 5 minutes in RSS mode.
🔵xRIT	-	1691/1695.15 MHz	Linear -	-
Not used in favour of the EumetCast service.
🟢DCP	TODO	1675.281 MHz	Linear ???	-
DCP data. Not supported due to lack of documentation.
🟢Telemetry	TODO	2247.5 MHz	RHCP -	-
Telemetry.

Meteosat-11 (MSG-4) [NORAD 40732]

15-07-2015 • Agency: EUMETSAT

Currently positioned at 9.5°E.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢PGS Raw data		1686.83 MHz	Linear 3.75 msym/s	-
Contains all raw SEVIRI channels - 1x panchromatic at 1.6 km/px, 3x VIS and 9x IR all at 4.8 km/px. New image every 15 minutes in standard FD scanning mode, every 5 minutes in RSS mode.
🔵xRIT	-	1691/1695.15 MHz	Linear -	-
Not used in favour of the EumetCast service.
🟢DCP	TODO	1675.281 MHz	Linear ???	-
DCP data. Not supported due to lack of documentation.
🟢Telemetry	TODO	2248.5 MHz	RHCP -	-
Telemetry.

Meteosat-9 (MSG-2) [NORAD 28912]

21-12-2005 • Agency: EUMETSAT

Currently positioned at 45.5°E. High inclination due to low propellant.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢PGS Raw data		1686.83 MHz	Linear 3.75 msym/s	-
Contains all raw SEVIRI channels - 1x panchromatic at 1.6 km/px, 3x VIS and 9x IR all at 4.8 km/px. New image every 15 minutes in standard FD scanning mode, every 5 minutes in RSS mode. Meteosat-9 operates in RSS mode (?)
🔵xRIT	-	1691/1695.15 MHz	Linear -	-
Not used in favour of the EumetCast service.
🟢DCP	TODO	1675.281 MHz	Linear ???	-
DCP data. Not supported due to lack of documentation.
🟢Telemetry	TODO	2245.5 MHz	RHCP -	-
Telemetry.

NOAA 15 [NORAD 25338]

13-05-1998 - 19-08-2025 | Agency: NOAA

This was the longest living NOAA POES satellite until being shut down due to political reasons. Decommissioning took two tries, as the satellite rebooted a few orbits after its first one. It only used a damaged emergency antenna for L-band due to the others interfering with the AMSU instrument, this made the transmission strength very weak. AVHRR came close to stalling on several occasions, but always recovered.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🔴APT		137.62 MHz	RHCP N/A	HVC Raw image
2x 4 km/px images, during day 1x IR + 1x VIS and 2x IR during night. FFT pic is from NOAA 19
🔴DSB		137.35 MHz	Linear 8320 sym/s	-
SEM, HIRS, Telemetry data.
🔴HRPT		1702.5/2247.5 MHz	RHCP 2x 665.4 ksym/s	NOAA Natural Color
Live full resolution operational imagery from all instruments
🔴GAC		2247.5 MHz	RHCP 2.6616 Msym/s	-
Full orbit dumps of all instruments, AVHRR only at 4 km/px. Dumped to Svalbard on every pass

NOAA 18 [NORAD 28654]

20-05-2005 - 06-06-2025 | Agency: NOAA

Second-to-last satellite of the POES constellation, reliably delivered data until June of 2025 where an S-band TPX issue occured, leading to the satellite’s prompt decommissioning.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🔴APT		137.9125 MHz	RHCP N/A	HVC
2x 4 km/px images, 1x IR + 1x VIS. Normally should be 2x IR during night, but a configuration error made the satellite transmit a VIS channel instead. FFT pic is from NOAA 19
🔴DSB		137.35 MHz	Linear 8320 sym/s	-
SEM, HIRS, Telemetry data. FFT pic is from NOAA 15
🔴HRPT		1707/2247.5 MHz	RHCP 2x 665.4 ksym/s	NOAA Natural Color
Live full resolution operational imagery from all instruments
🔴GAC		2247.5 MHz	RHCP 2.6616 Msym/s	-
Full orbit dumps of all instruments, AVHRR only at 4 km/px. Dumped to Svalbard on every pass

NOAA 19 [NORAD 33591]

06-02-2009 - 13-08-2025 | Agency: NOAA

Last satellite of the POES constellation, reliably delivered data until August of 2025 when NOAA claimed a battery issue occured, leading to the satellite’s prompt decommissioning.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🔴APT		137.1 MHz	RHCP N/A	HVC
2x 4 km/px images, 1x IR + 1x VIS during day, 2x IR during night.
🔴DSB		137.77 MHz	Linear 8320 sym/s	-
SEM, HIRS, Telemetry data. FFT pic is from NOAA 15
🔴HRPT		1698/2247.5 MHz	RHCP 2x 665.4 ksym/s	NOAA Natural Color
Live full resolution operational imagery from all instruments
🔴GAC		2247.5 MHz	RHCP 2.6616 Msym/s	-
Full orbit dumps of all instruments, AVHRR only at 4 km/px. Dumped to Svalbard on every pass

NOAA 20 (JPSS-1) [NORAD 43013]

18-11-2017 • Agency: NOAA

Low-earth-orbiting operational satellite with an ECT of 13:25 local time (ascending). VIIRS instrument has a couple of dead detectors presenting as lines in certain composites.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢HRD		7812 MHz	RHCP 15 Msym/s	-
Full resolution DB from all instruments. Has nulls everywhere except, most present when East from your reception position. They are least present when passing West from you at a 30°-50° elevation.
🟢Ka-band dumps	TODO	26703.4 MHz	RHCP ???	-
TODO
🟢Telemetry		2247.5 MHz	RHCP ???	-
Global telemetry downlink. The spikes present on the FFT are a part of the signal.

NOAA 21 (JPSS-2) [NORAD 54234]

10-11-2022 • Agency: NOAA

Low-earth-orbiting operational satellite with an ECT of 13:25 local time (ascending).
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢HRD		7812 MHz	RHCP 15 Msym/s	-
Full resolution DB from all instruments. Has a weaker null than JPSS-1, improved FEC helps mitigate it further.
🟢Ka-band dumps	TODO	26703.4 MHz	RHCP ???	-
TODO
🟢Telemetry		2247.5 MHz	RHCP 1.6 Msym/s	-
Global telemetry downlink. DC spike on the right side of the image is not part of the signal.

Oceansat-2 [NORAD 35931]

23-09-2009 • Agency: ISRO

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🔴Dumps	TODO	8212.5 MHz	RHCP 22.226 MHz	-
TODO
🟢Telemetry	TODO	2245 MHz	RHCP ???	-
TODO

Oceansat-3 (EOS-6) [NORAD 54361]

26-11-2022 • Agency: ISRO

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢Dumps	TODO	8275 MHz	RHCP 80 MSym/s	-
Dumps to Svalbard and unknown groundstation in India
🟢Telemetry	TODO	2250 MHz	RHCP ???	-
Dumps to Svalbard and unknown groundstation in India
🟢ARGOS	TODO	1703 MHz	RHCP 1 Msym/s	-
Commonly spotted in L-band, as it is active globally.

PAZ [NORAD 43215]

22-12-2018 • Agency: Hisdesat

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟡X-band dump	TODO	8150 MHz	RHCP ???	-
Dumps to Spain
🟡S-band dump	TODO	2285 MHz	RHCP ???	-
Dumps to Kiruna

PRETTY [NORAD 58023]

09-10-2023 - 10-2024 | Agency: ESA

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢VHF		137.78 MHz	RHCP ???	-
Signal is on the right hand side of the FFT image.
🟡S-band SSH		2250 MHz	RHCP ???	-
Dumps to Graz [AT].

PRISMA [NORAD 44072]

22-03-2019 • Agency: ASI

Encrypted on all downlinks
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢X-band 1	TODO	8120 MHz	RHCP 77.5 Msym/s	-
Encrypted dumps to Matera
🟢X-band 2	TODO	8320 MHz	RHCP 77.5 Msym/s	-
Encrypted dumps to Matera
🟢S-band	TODO	2283.5 MHz	RHCP ???	-
Encrypted dumps to Matera

Proba-1 [NORAD 26958]

22-10-2001 • Agency: ESA

Satellite is only enabled for testing, normally does not transmit any imagery. The satellite suffered some memory issues making CHRIS imagery appear corrupted.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢Dumps	TODO	2235 MHz	RHCP 2 Msym/s	-
Dumps to Redu [BE]

Proba-2 [NORAD 36037]

02-11-2009 • Agency: ESA

This satelltie performs sun imaging using its SWAP instrument. Dumps imagery on every pass.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢Dumps		2235 MHz	RHCP 2 Msym/s	-
Dumps on every pass to Redu [BE]

Proba-V [NORAD 39159]

07-05-2013 • Agency: ESA

Mission was suspended due to insufficient light caused by orbital drift, but it has since drifted back to a more suitable ECT allowing the mission to resume soon.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟡X-band dumps	TODO	8090 MHz	RHCP 35 msym/s	-
Dumps to Kiruna. Mission was suspended due to insufficient light caused by orbital drift, but it has resumed.
🟢S-band dumps		2235 MHz	RHCP 1.919 Msym/s	-
Contains Vegetation instrument imagery, including moon calibration every once in a while.

Proba-VCC (PVCC) [NORAD 58025]

09-10-2023 • Agency: ESA

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢X-band dumps	TODO	8175.5 MHz	RHCP 50 Msym/s	-
TODO
🟢S-band dumps	TODO	2221 Mhz	RHCP 2 Msym/s	-
TODO

SMAP [NORAD 40376]

31-12-2015 • Agency: NASA

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢X-band	TODO	8180 MHz	??? ???	-
TODO
🟢S-band dumps	TODO	2247.3 MHz	??? 590 ksym/s	-
Dumps to Svalbard

SMOS [NORAD 36036]

02-11-2009 • Agency: ESA

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟡X-band	TODO	8150 MHz	LHCP 9 Msym/s	-
Transmits microwave sounder imagery
🟡S-band	TODO	??? MHz	RHCP 838.878 ksym/s	-
TODO

SWOT [NORAD 54754]

16-12-2022 • Agency: NASA

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢X-band dumps	TODO	8205 MHz	??? ???	-
Dumps to Svalbard
🟢S-band dumps		2282.4 MHz	??? ???	-
Dumps to Svalbard [NOR], Inuvik [CAN], Hartebeesthoek [ZA], Kourou [FRG] and Kerguelen [FRA]

Saral [NORAD 39086]

25-02-2013 • Agency: ISRO + CNES

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢X-band dumps	TODO	8212.5 MHz	RHCP 16 Msym/s	-
Dumps to Kiruna
🟢S-band dumps		2245 MHz	??? ???	-
Dumps to Kiruna
🟢ARGOS	TODO	1698.4 mhz	RHCP 400 ksym/s	-
Commonly spotted in L-band, as it is active globally.

SciSat-1 [NORAD 27858]

13-08-2003 • Agency: CSA

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢Dumps	TODO	2232 MHz	RHCP 2 Mysm/s	-
Dumps to Kiruna [SWE], Quebec [CAN] and other groundstations.

Sentinel-6 [NORAD 46984]

21-11-2020 • Agency: EUMETSAT + NASA

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢Dumps	TODO	8090 MHz	RHCP 75 Msym/s	-
TODO
🟢Telemetry	TODO	2256.75 Mhz	RHCP 500 ksym/s	-
TODO

Stereo-A [NORAD 29510]

26-10-2006 • Agency: NASA

Stereo-A (Ahead) is currently in a heliocentric orbit around the sun, performs imaging of the Corona as well as SEM monitoring. Launched with its sister satellite, Stereo-B (Behind).
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢Low rate		8443.52 MHz	RHCP 3800 sym/s	-
TODO
🟢High rate	TODO	8443.52 MHz	RHCP 1.44 Msym/s	-
TODO

Stereo-B [NORAD 29511]

26-10-2006 - 01-10-2014 | Agency: NASA

Stereo-B (Behind) is in a heliocentric orbit around the sun with its sister satellite, Stereo-A (Ahead). It was used for sun imaging and SEM monitoring. A planned test of the spacecraft’s automation just before the satellite passed behind the sun failed on 01-10-2014, causing the satellite to spin too quickly for the reaction wheels to correct it, resulting in a loss of communication with the spacecraft. After 22 months, on 21-08-2016, communications were restored and recovery attempts were performed through to September. On 23-09-2016, the carrier wave stopped being detected. It is suspected a frozen thruster valve came loose, increasing the spin rate even more. All subsequent attempts to find the satellite have failed.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🔴Low rate		8443.52 MHz	RHCP 3800 sym/s	-
TODO
🔴High rate	TODO	8443.52 MHz	RHCP 1.44 Msym/s	-
TODO

Suomi NPP [NORAD 37849]

28-10-2011 • Agency: NOAA

Prototype satellite of the cancelled NPOESS series. Flown to validate the planned instrumentation, long outlived its design life of 5 years. The satellite ocassionally experiences issues with its clock, making imagery transmit with erroneous dates.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢HRD		7812 MHz	RHCP 15 Msym/s	-
Full resolution DB from all instruments. Has nulls everywhere except, most prominent when West from your reception spot. They are least present when passing East from you at a 30°-50° elevation. Null presents itself as slow fading. Spike on the left is not a part of the signal.
🟢Dumps	TODO	8212.5 MHz	RHCP ???	-
TODO, dumps to Svalbard
🟢Telemetry	TODO	2247.5 MHz	RHCP ???	-
Global telemetry downlink.

Swarm-A [NORAD 39452]

22-11-2013 • Agency: ESA

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢Dumps		2249 MHz	??? ???	-
TODO

Swarm-B [NORAD 39451]

22-11-2013 • Agency: ESA

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢Dumps		2249 MHz	??? ???	-
TODO

Swarm-C [NORAD 39453]

22-11-2013 • Agency: ESA

TODO
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢Dumps		2249 MHz	??? ???	-
TODO

TUBIN [NORAD 48900]

30-06-2021 - 16-12-2025 | Agency: TU Berlin

Tubin was a satellite known for its capability to track objects on the ground while orbitting, reentered in December 2025.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🔴X-band dumps	TODO	8392.5 MHz	RHCP 12.3 Msym/s	-
Dumped to Berlin and Svalbard
🔴S-band 1		2263 MHz	RHCP 1.2 Msym/s	-
Dumped to Berlin. Left hand bump on the FFT image.
🔴S-band 2		2266 MHz	RHCP 1.2 Msym/s	-
Dumped to Berlin. Right hand bump on the FFT image.

Terra [NORAD 25994]

18-12-1999 • Agency: NASA

NASA EOS satellite, DB transmissions stopped because of power supply issues.
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢Ka-band TDRS dumps	TODO	~15000 Mhz	RHCP ???	-
Tightly beamed
🔵X-band	TODO	8212.5 MHz	RHCP 13.125 (*2) Msym/s	-
X-band disabled due to power issues, QPSK subconstellation contained other instrument data at 26,25 Msym/s
🟢Telemetry	TODO	2287.5 MHz	RHCP ???	-
Primarily to TDRS

Yunhai 1-01 [NORAD 41857]

11-11-2016 • Agency: NSMC

Encrypted military satellite
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢L-band DB	TODO	1704 MHz	RHCP 4 Msym/s	-
Encrypted, commonly spotted in L band as it is enabled globally

Yunhai 1-02 [NORAD 44547]

25-09-2019 • Agency: NSMC

Encrypted military satellite
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢L-band DB	TODO	1704 MHz	RHCP 4 Msym/s	-
Encrypted, commonly spotted in L band as it is enabled globally

Yunhai 1-03 [NORAD 53877]

21-09-2022 • Agency: NSMC

Encrypted military satellite
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢L-band DB	TODO	1704 MHz	RHCP 4 Msym/s	-
Encrypted, commonly spotted in L band as it is enabled globally

Yunhai 1-04 [NORAD 58073]

15-10-2023 • Agency: NSMC

Encrypted military satellite
Transmitted signals:

Name	FFT image	Frequency	Polarization, Symbol rate	Sample data
🟢L-band DB	TODO	1704 MHz	RHCP 4 Msym/s	-
Encrypted, commonly spotted in L band as it is enabled globally
